Additel 226Ex - I;P Converter; Figure 28 I;P Converter

77
 When the pressure switch moves (open/close) during the task, the calibrator will automatically record the
pressure value at the moment of the action, without manual input.
5. Finish the task
Refer to Finish the task in paragraph 6.1.1.
6.1.4 I/P Converter
1. Connect to DUT
 Connect the external pressure module to the LEMO port A or B.
 As shown in the Figure 28, connect the DUT output with calibrator’s electric module.
Figure 28 I/P converter
