76
Table 25 Pressure switch task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Pressure type GP / AP / DP Pressure type of DUT
Range Numbers Input range of DUT
Accuracy
0.5%, 1%, 1.5%, 2%,
2.5%, 4%, custom
Accuracy of DUT. If choose custom, the input number means the
accuracy level of this pressure switch.
Set point Numbers Action set point of the DUT
Set action type Open / closed Action type of the DUT
Dead band Numbers Set the dead band of DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
 For part of the content, refer to Start the task in paragraph 6.1.1
