7.6 Simulate transmitter
The calibrator provides simulate transmitter function, which can easily use the calibrator as a transmitter. Click the
simulate transmitter icon on the main interface to enter the simulate transmitter function. Before using it, you should set
the transmitter function in the setting menu. The detail is shown below:
Table 40 Simulate transmitter settings
Subject Valid value Description
Type of transmitter
Pressure transmitter / TC-temperature
Transmitter / RTD- temperature
transmitter / signal convertor
Select transmitter type
Initial range Value (the unit depends on the transmitter type) Transmitter input range
Resolution 4 / 5 / 6 Transmitter resolution
Scaled range Value (select frequency, voltage or current as unit) Transmitter output range
Transfer function Linear / square / square root Transfer function
Sensor type Type of the sensor Available for RTD & temperature simulate transmitter
Sensor CJC type Auto / fixed Available for simulate transmitter
CJC value -80 ~ 300 Available for TC simulate transmitter
Wires 2 / 3 / 4 Available for RTD-simulate transmitter
After the setting is completed, click the confirm button, and the calibrator will generate the corresponding output signal
for the measured input signal based on the set transmission method. The measured signal and the converted output
