97
The calibrator will automatically record the measured signal value at the moment, the current display of DUT
needs to be input manually.
5. Finish the task
Refer to Finish the task in paragraph 6.1.1.
6.4 Calibrate loop devices
6.4.1 Loop indicators
1. Connect to DUT
Connect the DUT input with the electrical output module of the calibrator, as shown in the Figure 22(for current
output) or 21(for voltage output).
2. Create the task
Create the corresponding DUT tasks as described above and fulfill the necessary information. See table below.
Table 34 Loop readout task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S / N
Model Numbers, letters, symbols Model of DUT
Range (4~20)mA,(0~10)mA,(0~20)mA,(1~5)V,(0~5)V,(0~10)V, custom Input range of DUT
Accuracy 0.025%,0.05%,0.1%,0.16%,0.25%,0.4%,1%,1.6%,2.5%,4%,custom Accuracy of DUT
