96
Table 33 Tachometer task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Input Numbers Input range of DUT, variety of flow units available
Output Numbers
Output range of DUT, switch the unit to change the output signal
type (current/ voltage/ frequency)
Decimal digits Option 0~3 The last decimal digit of the DUT’s display
Accuracy
0.06%,0.1%,0.16%,0.25%,0.4%,
0.6%,1%,1.6%,2.5%,4%,custom
Accuracy of DUT, the output is customizable
Transfer function Linear / square / square root Transfer function of the DUT signal
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
For part of the content, refer to Start the task in paragraph 6.1.1.
