3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
 For part of the content, refer to Start the task in paragraph 6.1.1.
 The calibrator will automatically generate a continuous pulse output according to user's settings. After all pulse
are output, users will need to enter the current accumulative flow value of the DUT into the calibrator.
 Repeat the above steps until all task cycles finish.
5. Finish the task
Refer to Finish the task in paragraph 6.1.1.
6.3.4 Tachometer/ vortex meters
1. Connect to DUT
 According to the output signal type of DUT, connect the DUT output with the current measurement (Figure 8) or
voltage/ frequency measurement (Figure 7) of the calibrator.
2. Create the task
Create the corresponding DUT tasks as described above and fulfill the necessary information. See table below.
