module A values and units
External
module B
Module real time pressure
values and units
Click to enter to view the module information
The following functions are also supported in the DP module management.
Zero: when enabling the DP module and both external A and B are online, users can run the zero operation; the zero
offset will be saved and use for calculating the differential pressure.
Cancel zero: cancel the zero offset when performing the zero operation, set the zero offset to 0.
7.8 Wiring help
The wiring help function in the calibrator can help users to connect the wires correctly under various working conditions
of the calibrator. It can be entered by clicking the "Wiring help " menu in each channel, or by clicking the "wiring help"
icon in the main interface of the device.
