2.Create the task
Create the corresponding DUT tasks as described above, and fill out the necessary information, as shown below.
Table 26 I/P Converter task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/ N
Model Numbers, letters, symbols Model of DUT
Pressure type GP / AP / DP Pressure type of DUT
Input
(4～20)mA, (4～12)mA, (12～20)mA,
custom
Input range of DUT
Output Numbers Output range of DUT
Accuracy
0.025%, 0.05%,0.1%, 0.16%, 0.25%,
0.4%, 1%, 1.6%, 2.5%, 4%, custom
Accuracy of DUT. If choose custom, the input number means the
accuracy level of this I/P converter.
Transfer function Linear / square / square root Transfer function of the DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
