72
3. Task setting
After starting the task, go to the task setting interface and set the required information for the task to run. If multiple
pressure modules are connected, you will also need to select which module to use to perform the task.
Table 22 Task running setting
Subject Valid value Description
Set point list
The effective value of the set
point pressure depends on the
pressure range of the DUT; up
to 17 points can be set
Set the calibration point for this task, and the calibrator will automatically set the
default calibration points in equal difference according to the range of the DUT and
the number of set points. However, you can click the "Set Point List" item to
manually set them. At this time, the unit of the set point is consistent with the unit of
the DUT. Use the arrow button on the bottom of the screen or click the number of
set points and then enter the number of set points through the keyboard to change
the number of set points or modify a set point individually.
Cycle times 1, 2, 3 Cycles during calibration
Strokes One way/ Round trip Stroke during calibration
Tapping On/ off Enable or disable the tapping
4. Start the task
Click “Start” button to start the task.
Click button or to switch between lines mode and table mode.
Calibration process:
1
）
After the pressure is controlled to the first set point by the pressure control device, read the displayed value of
the DUT and enter it on the task interface.
