11
CE certificate TUV IEC61326, IEC61010
ROHS conformity ROHS II Directive 2011/65/EU, EN50581:2012
Protection level IP67,1 meter fall test
Mechanical vibration 5g for low and high frequency
Mechanical impact 8g
Salt spray test 48 hours
Refresh rate 3 times/s
Bus configuration HART
Communication Isolated USB-TYPE C (slave),Bluetooth BLE
Environmental measure
built-in barometric sensor (can be calibrated by users, (60～110)kPa. a, annual accuracy ±55Pa) and
temperature sensor (no accuracy, for reference only)
Electric measure module
 voltage measure: ±300mV, ±30V  current measure ±30mA  switch measure
 frequency measure: (0.01~50000)Hz  pulse count: 0~9999999
 loop power: 20V
Electric output module
 voltage output: (0~10.5)V  current output: (0~25)mA, support SOURCE and SINK
 frequency output: (0.01~50000)Hz  pulse output: 0~9999999
Temperature measure &
simulate output module
 mV measure & output: (-10~75)mV
 resistance measure & simulate resistance output: (0~400~4000)Ω
 TC measure & TC simulate output  RTD measure & RTD simulate output
 Internal CJC measure
External pressure
module
Dual channel LEMO ports, support two digital pressure modules
