2. Create the task
Create the corresponding DUT tasks as described above and fill out the necessary information.
Table 37 Limit switches task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Range
(4~20)mA, (0~10)mA, (0~20)mA, (1~5)V, (0~5)V, (0~10)V,
custom
Input range of DUT
Accuracy 0.5%, 1%, 1.5%, 2%, 2.5%, custom Accuracy of DUT
Set point Numbers Action set point of DUT
Set action type Open/ closed Action type of DUT
Dead band Numbers Switch difference range of the DUT(dead band)
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
