Additel 226Ex - Page 91

80
Table 27 Loop readout task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Input Numbers Input range of DUT, switchable temperature units
Sensor type TCs or RTDs optional Sensor type of the DUT
Accuracy
0.06%, 0.1%, 0.16%, 0.25%, 0.4%,
0.6%, 1%, 1.6%, 2.5%, 4%, custom
Accuracy of DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
 For part of the content, refer to “Start the Task” in paragraph 6.1.1.
 During the task, the calibrator simulates and outputs a temperature signal to the DUT, and users need to manually
input the value.
5. Finish the task
