82
2. Create the task
Create the corresponding DUT tasks as described above and fill out the necessary information.
Table 28 Temperature transmitter task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Input Numbers Input range of DUT
Sensor TCs or RTDs optional Sensor type of the DUT
Output
Analog signal:
4~20mA, 0~10mA, 0~20mA, 1~5V, 0~5V, 0~10V, custom
Output range of DUT
HART devices: Process variables, percentage,
Output current, loop current
Accuracy
0.06%, 0.1%, 0.16%, 0.25%, 0.4%,
0.6%, 1%, 1.6%, 2.5%, 4%, custom
Accuracy of DUT, the input is customizable
Transfer function Linear / square / square root Transfer function of the DUT signal
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
