87
2. Create the task
Create the corresponding DUT tasks as described above and fill out the necessary information. See below table.
Table 29 Temperature switch task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Range Numbers Input range of DUT
Sensor TCs or RTDs optional DUT sensor type
Accuracy
0.06%, 0.1%, 0.16%, 0.25%, 0.4%,
0.6%, 1%, 1.6%, 2.5%, 4%, custom
Accuracy of DUT, the input is customizable
Set point Numbers Action set point of DUT
Set action type Opened/ closed Action type of DUT
Dead band Numbers Dead band range of the DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
