ADT-HC4500 Flame/Plasma Cutting Machine CNC System
- 59 -
Flame:
p Fixed ignition cycle M52
q Fixed torch down cycle M71
r Fixed preheating cycle M74
s Fixed perforating torch up cycle M72
t Cutting oxygen on M12
u Fixed perforating torch down cycle M73
Plasma:
A. When height adjustment system is integrated:
Height adjustment on M22
Start arc M12
Wait for arc voltage test signal (IN0)
When arc starts, the height adjuster initializes positioning automatically (height adjust with initial
positioning), perforates, delays, and sends a successful arc voltage test signal to the controller.
B. When height adjustment system isn’t integrated:
p Start arc, start arc delay M12
q Perforating, perforating delay
Actions after starting
The user can customize the function of M07 according to actual requirements.
2) [F2] is to customize M08 instruction, and the default M08 is to turn off the cutting oxygen, and the
flow is:
Flame:
p Cutting oxygen off M13
q Fixed torch up cycle M70
Plasma:
p Turn off arc M13
q Turn off height control M23
The use can customize M08 to M80 (turn off all outputs) according to requirements. When performing M08, all
valves will be turned off to save gas.
3) [F3]: Clear the data of current line
4) [F4]: Add a line below current line
5) [F5]: Delete current line
6) [F6]: Saved the edited content
7) [INS] key: Activate the help of current interface.
Note: After customizing M07, M08 instructions, please change [F1] (Configure) in [F4] (Parameter) into
“Custom”.
