MX2800 STS-1 User Manual Transaction Language 1 (TL1), Section 9
TL1 Error Codes
61204659L1-1A 9-17
NOTE
<aid> and <ctag> are optional parameters. The placemarker : must remain
in place. The default <aid> is All and the default <ctag> is 1.
TL1 RTRV examples:
RTRV-T1::109:4; (This returns the values for all parameters related to T1 #9.)
NOTE
If no parameter is specified, all valid parameters to the <aid> are
retrieved.
RTRV-STS1:UNIT-1:301:1:::STS1CVTHRS; (This returns the value of Code Violation Threshold for the
STS-1.)
RTRV-VT1:UNIT-1:205:2:::LINECDE; (This returns the Line Code Type on VT1 #5.)
RTRV-EQPT:UNIT-1:404:5:::PSTEMPCRITRLY; (This returns the status [enabled or disabled] of the
alarm relay for power supply A temperature critical setting.)
Data Dictionaries
The data dictionaries that follow are to be used while performing TL1 editing or retrieve commands. Each
data dictionary contains four columns. The columns are as follows:
• Keyword gives the values to be placed in the <keyword> portion of the edit command.
• Type describes the type of <value> that is required to be entered in the edit command.
– ENUM requires a text and/or number string to be entered as the <value>.
– Y/N requires a
Y or N representing yes or no to be entered as the <value>.
– INT requires that an integer be entered as the <value>.
• Domain describes valid entries that may be entered into the <value> portion of the edit command.
• Description explains each of the edit or retrieve commands.
