MX2800 STS-1 User Manual Configuration, Section 3
System Management
61204659L1-1A 3-17
CAUTION
Configuration changes to Local IP Address, Gateway IP Address, Subnet
Mask, Management Port, Modem Mode, Modem Baud Rate, and IP Hosts
will not be implemented unless all Telnet sessions are closed. Changes
made while a Telnet menu session is active will invoke a warning
message on the console.
NOTE
If the unit is not equipped with an internal modem, the Management Port
option and Dialup Options will not be available.
Management Options
Local IP Address
This option is utilized to enter the MX2800 STS-1 IP address. This IP address applies to the LAN or
modem port (when configured for PPP or SLIP). This address is available from the network administrator.
Gateway IP Address
If the MX2800 STS-1 and the network manager are connected through a gateway node, a gateway IP
address for the MX2800 STS-1 is required in this field. If an IP packet is to be sent to a different network,
the unit sends it to the gateway.
Subnet Mask
This option is utilized to enter the subnet mask of the MX2800 STS-1. This address is available from the
network administrator.
Management Port
This option is utilized to assign the management port as either LAN or Modem. The Modem setting applies
only to units equipped with an internal modem.
Dialup Options
This option is utilized to configure the dialup capabilities of the MX2800 (see Figure 3-11). These options
apply only to units equipped with an internal modem.
