61204659L1-1A 3-1
SECTION 3, CONFIGURATION
Section 3
Configuration
Configuration of the MX2800 STS-1 is accomplished via either the 10Base-T ethernet connection, a
SLIP/PPP modem port, or a VT-100 terminal. Figure 3-1 shows the Configuration menu screen. Figure
3-2, Figure 3-3, and Figure 3-4 show the menu tree.
NOTE
A Telnet menu session has priority over a terminal menu session through
the craft port. If a terminal menu session is active when a Telnet menu
session is initiated, the terminal menu session will be disabled until the
Telnet menu session is closed.
Figure 3-1. Configuration Menu
Detailed descriptions of the menu options shown in Figure 3-1 are given in the following:
• Network Interface on page 3-5
• VT Interface on page 3-9
• System Management on page 3-16
• Utilities on page 3-37
• Save Configuration and Alarm Log on page 3-43
