Section 9, Transaction Language 1 (TL1) MX2800 STS-1 User Manual
TL1 Error Codes
T1 Data Dictionary
Table 9-8 contains entries that are used to edit or retrieve options for the T1 portion of the MX2800. When
performing TL1 edit commands from this table, the value of
rr should be T1, and the <aid> value should be
one of the following:
101 - DS1#1
102 - DS1#2
.
.
.
128 - DS1#28
Table 9-8. TL1 Editing Data Dictionary for T1
Keyword Type Domain Description
DSXCAISRLY Y/N Y or [N] Provisions alarm relay response for DSX
CAIS alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
DSXCVTHRS ENUM One of the following:
•DISABLE
•1E3
•1E4
•1E5
•1E6
Indicates a limit on the number of code
violations accepted by the unit over a
single T1/E1 before the unit switches
controller cards
• 1E3 - 1 out of every 1,000 bits on a sin-
gle T1/E1 contains a CV
• 1E4 - 1 out of every 10,000 bits on a
single T1/E1 contains a CV
• 1E5 - 1 out of every 100,000 bits on a
single T1/E1 contains a CV
• 1E6 - 1 out of every 1,000,000 bits on a
single T1/E1 contains a CV
DSXLAISRLY Y/N Y or [N] Provisions alarm relay response for the
DSX LAIS alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
DSXLOSRLY Y/N Y or [N] Provisions alarm relay response for the
DSX LOS alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
DSXPROTTHRS INT 1-28 Number of Enabled lines that must fail
before a protection switch occurs
