MX2800 STS-1 User Manual Transaction Language 1 (TL1), Section 9
TL1 Error Codes
61204659L1-1A 9-21
VT1 Data Dictionary
Table 9-7 contains entries that are used to edit or retrieve options for the VT1 portion of the MX2800.
When performing TL1 edit commands from this table, the value of
rr should be VT1 and the <aid> value
should be one of the following:
201 - VT1#1
202 - VT1#2
.
.
.
228 - VT1#28
Table 9-7. TL1 Editing Data Dictionary for VT1
Keyword Type Domain Description
DIAGVTTESTSTATE ENUM One of the following:
• DATAMODE
• TRIBUTARY
• ANALOG
•DIGNET
•CODEC
•CSULPBK
•CSUBERT
•VTBERT
•LINEBERT
Identifies DS2 Diagnostic Loopback
• Refer to Data Mode on page 6-2
• Refer to Tributary on page 6-3
• Refer to Analog Network on page 6-3
• Refer to Digital Line/Net on page 6-4
• Refer to Codec Line/Net on page 6-4
• Refer to CSU Loopback on page 6-5
• Refer to CSU Loopback w/BERT on
page 6-5
• Refer to VT BERT on page 6-6
• Refer to Line BERT on page 6-7
LBO ENUM One of the following:
• 0TO133
• 133TO266
• 266TO399
• 399TO533
• 533TO655
• MINUS7R5
• E10TO3000
•UNAVAIL
Line Build Out (returns UNAVAIL if VT is
unequipped)
LINECDE ENUM One of the following:
•AMI
•B8ZS
•E1AMI
• E1HDB3
•UNAVAIL
Line Code (returns UNAVAIL if VT is
unequipped)
