9-20 61204659L1-1A
Section 9, Transaction Language 1 (TL1) MX2800 STS-1 User Manual
TL1 Error Codes
STS1CFGSEC
EXTCLK
ENUM One of the following:
• DISABLED
•EXTB
Provision secondary clock reference (Disabled
or External B)
STS1CVTHRS ENUM One of the following:
• Disable
•1E3
•1E4
•1E5
•1E6
Indicates a limit on the number of code viola-
tions accepted by the unit over the DS3 before
the unit switches controller cards
• 1E3 - 1 out of every 1,000 bits contains a CV
• 1E4 - 1 out of every 10,000 bits contains a
CV
• 1E5 - 1 out of every 100,000 bits contains a
CV
• 1E6 - 1 out of every 1,000,000 bits
contains a CV
STS1MAXNUMSW INT 0, 1, 2, ..., N Maximum number of times per hour the unit is
allowed to switch between controller cards (if
number is exceeded, the unit will issue a trap)
STS1MINSWPERIOD INT 0, 1, 2, ..., N Number of seconds that must pass after a
protection switch before another protection
switch will be allowed
STS1PROT Y/N Y or [N] Identifies status of system network protection
• Yes (Y) - enables system network protection
• No (N) - disables system network protection
SYSCARDCOMMRLY Y/N Y or [N] Identifies status of System Communication Fail
alarm relay
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
SYSCARDRLY Y/N Y or [N] Identifies status of System Controller Card
alarm relay
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
TMG ENUM One of the following:
•LPD
•INT
• EXTNONREV
•EXTREV
Identifies timing supply for the DS3
• Loop timing
• Internal (free-run) timing
• External non-revertive
• External revertive
Table 9-6. TL1 Editing Data Dictionary for STS-1 (Continued)
Keyword Type Domain Description
