MX2800 STS-1 User Manual Status, Section 4
STS-1 State
61204659L1-1A 4-3
Network Port Mapping
This entry contains a description of the mapping between network ports and controller cards.
A redundant system with circuit protection will display the following:
A redundant system with network protection will display the following:
SLM-P Path Signal
Level Mismatch
The controller card is detecting a signal label mismatch. A received signal label is
mismatched if the received C2 byte does not indicate unequipped (0) or “VT
structured payload” (2).
UEQ-P Path
Unequipped
The path is unequipped if it is not provisioned. Byte C2 of the STS path overhead
is set to zero.
*Critical Alarm
Table 4-2. STS-1 Alarm Descriptions (Continued)
Alarm Meaning Description
Card A Port A | Card B Port A
Card A Port A | Card B
Port B
OR
Card A Port B | Card B
Port A
