ADTRAN MX2800 STS-1 - Configure Alarm Relays

A-4 61204659L1-1A
Appendix A, Acceptance Test Procedure MX2800 STS-1 User Manual
Configure the Unit for Test
8. Press ESC to return to the Configure VT Interface screen
9. Select #32 – XCV Threshold, and set to Disabled
10. Press
ESC to return to the main Configuration Menu
Configure Alarm Relays
Numerous alarm configuration options are available on the MX2800. This test will only be utilized to
generate one CRITICAL and one NON-CRITICAL alarm. This determines that the two sets of alarm
contacts are operating and wired correctly, and that the appropriate alarm indications are relayed back to
the Central Office alarm panel.
1. From the main
Configuration menu, select System Management. From this menu, select Alarm Relay
Configuration
.
2. Select
STS-1 Alarms. From this menu, select LOS = Enabled (This will generate a CRITICAL alarm
when the STS-1 port sees a Loss of Signal condition.)
3. Press
ESC to return to the Alarm Relay Configuration menu.
4. Select
VT/Port Alarms. From this menu, select LOS = Enabled (This will generate a NON-CRITICAL
alarm when one of the DS1 ports detects a Loss of Signal condition.)
5. Press
ESC to return to the Alarm Relay Configuration menu.
