MX2800 STS-1 User Manual Transaction Language 1 (TL1), Section 9
TL1 Error Codes
61204659L1-1A 9-27
DIAGLPBKTIMEOUT ENUM One of the following:
•DISABLE
•1-MIN
•5-MINL
• 10-MIN
• 15-MIN
• 30-MIN
• 45-MIN
•1-HR
Identifies the amount of time before a
Diagnostic Loopback will time out
• DISABLE - timeout is disabled
• 1-MIN - timeout value is one minute
• 5-MINL - timeout value is five minutes
• 10-MIN - timeout value is ten minutes
• 15-MIN - timeout value is 15 minutes
• 30-MIN - timeout value is 30 minutes
• 45-MIN - timeout value is 45 minutes
• 1-HR - timeout value is 60 minutes
DIAGRESET Y/N Y or [N] Resets Diagnostic Loopbacks
• Yes (Y) - reset the diagnostic loopback
• No (N) - do not reset the diagnostic
loopback
PSBATTERYLOWRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Battery Low alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
PSCHARGERFAILRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Charger Fail alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
PSFANFAILRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Fan Fail alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
PSMALFNCRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Malfunction alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
PSPOWERFAILRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Power Fail alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
PSPOWERLOWRLY Y/N Y or [N] Provisions alarm relay response for the
Power Supply Power Low alarm
• Yes (Y) - enables alarm relay response
• No (N) - disables alarm relay response
Table 9-9. TL1 Editing Data Dictionary for EQPT (Continued)
Keyword Type Domain Description
