Model A
2
O
®
Advanced Automated Osmometer User’s Guide
Using sample volumes below the minimums specified
could result in:
• Insufficient sample being aspirated for testing.
• The pipettor striking the bottom of the sample receptacle,
causing damage to the product or receptacle.
NOTES
• For best performance when using low volume insert tubes, it is rec-
ommended that they be placed in a 75 mm tall primary tube.
• The minimum volumes listed must be present above the gel separa-
tion layers of serum collection tubes after centrifuging.
• To ensure proper liquid level detection when testing liquids with
extremely low dielectric properties, such as de-ionized water, use a
primary tube filled to near capacity with the liquid.
• To ensure proper liquid level detection when testing samples con-
tained in ampules, use a lint-free cloth or swab to carefully remove
any liquid film present at the ampule opening.
20
Table 2: Minimum Sample Volumes in Sample Receptacles
Minimum Sample Volume (µL)
Nominal Tube Size Spherical Flat Conical
(Diameter) Bottom Bottom Bottom
11 mm 450 600
12 mm 500 750
13 mm 550 850
14 mm 650 1000
15 mm 700 1150
16 mm 750 1300
17 mm 800 1450 450
Nominal Ampule, Vial, or Insert Volume Minimum Sample Volume (µL)
2 mL Ampule 400
5 mL Ampule 950
2 mL Vial 650
1 mL Insert, Conical Bottom 300
3.5 mL Insert, Conical Bottom 500
