Model A
2
O
®
Advanced Automated Osmometer User’s Guide
Figure 17: The Test Setup Screen
Test Indicator button
The arrow on the T
est Indicator button moves during a test.
Menu screen
When the Menu button is pushed, the display changes as shown above
(Figure 14). Pressing any of the six large buttons on the screen causes a
different screen to be displayed. See the following sections for a
detailed description of each of those screens.
Test Setup screen
The Test Setup screen (Figure 17) is used to set the parameters for a test.
The actual appearance of the screen depends on whether or not “Named
Protocols” are enabled. Changes to settings on this screen can be saved
as a specific protocol.
Test Protocol drop-down menu
For convenience, specific combinations of settings can be saved as a
“Named Protocol”. The Test Protocol drop-down list allows you to
recall a saved protocol. Once recalled, the relevant parameters are dis-
To Next Page
