Advantech ADAM-6256 User Manual

ADAM-6200 User Manual 174
B.1.6 Analog Output Range code
Example The command asks the specific module at address 01h to send ana-
log output range code value from analog input channel 3.
ASCII Command: #01BE03(cr)
Response: !010147(cr)
B.1.7 Digital Input/Output Command Set
Range Code HEX
+/- 10V 0x0143
+/- 5 V 0x0142
0 ~ 10V 0x0148
0 ~ 5V 0x0147
0 ~ 20 mA: 0x0182
4 ~ 20 mA: 0x0180
Function Description Command Example
Read Channels
Asks a specified input
module to return the
status of all
channels
Cmd: $aa6(cr)
Ret:!aannnnnn (cr)
Send: $016(cr)
Receive:
!01000124(cr)
Write all DO chan-
nels
Writes specified val-
ues to all channels
simultaneously
Cmd: #aa00nnnn(cr)
Ret:>aa(cr)
Send: #0100007F(cr)
Receive: >01(cr)
Write a single DO
channel
Writes specified val-
ues to a single channel
Cmd: #aa1c01(cr) or
#aa1c00(cr)
Ret:>aa(cr)
Set channel 2 to logic
1
Send: #011201(cr)
Receive: >01(cr)
Read DI Channel
Counter Value
Returns the counter
value from specified DI
channels in
a specified module
Cmd:
$aaJCFFFFssmm(cr)
Ret:>aa(data)… (cr)
Send:
$01JCFFFF0102(cr)
Receive:
>01000000020000000
6(cr)

Advantech ADAM-6256 Specifications

General

Digital Input Channels	16
Digital Output Channels	16
Communication Interface	Ethernet
Input Voltage	10 to 30 VDC
Protocols	Modbus RTU
Storage Temperature	-20°C to +70°C
Humidity	10 to 95% RH

Summary

Chapter 1 Product Overview

1.2 Feature Highlights

Key features of the ADAM-6200 series, including installation, IT integration, and management.

Chapter 2 Product Specifications

2.1 General Specification

2.2 Analog Input Module (ADAM-6217)

Details the specifications for the ADAM-6217 analog input module.

2.3 Analog Output Module (ADAM-6224)

Details the specifications for the ADAM-6224 analog output module.

2.4 Digital Input/Output Modules (ADAM-6250/6251/6256)

Details specifications for ADAM-6250, 6251, and 6256 digital I/O modules.

2.5 Relay Output Modules (ADAM-6260/6266)

Chapter 4 System Configuration

4.1 ADAM.NET Utility (software)

4.3 Configure ADAM-6200 with ADAM.NET Utility

Guides users on configuring the ADAM-6200 module using the ADAM.NET Utility.

4.3.2 General Configuration

4.3.3 I/O Configuration

Details how to configure individual I/O channels for specific modules.

4.3.4 Peer to Peer

4.3.5 GCL

Introduces the Graphic Logic Condition (GCL) feature for standalone control.

4.3.6 Remotely Monitoring and Control via Web Server

Appendix A I/O Modbus Mapping Table

A.1 I/O Modbus Mapping Table

Appendix B ADAM-6200 ASCII Commands

B.1 ASCII Commands for ADAM-6200 modules

Appendix C REST for ADAM-6200

C.2 REST Resources for ADAM
