Advantech ADAM-6256 User Manual

131 ADAM-6200 User Manual
Appendix A I/O Modbus Mapping Table
3. Type Code Table
A.1.4 ADAM-6250 15-ch Digital Input/Output Module
Address (0X):
Input Range Type Code (HEX)
0 ~ 20 mA 0x0182
4 ~ 20 mA 0x0180
0 ~ 10 V 0x0148
0 ~ 5 V 0x0147
+/- 10 V 0x0143
+/- 5 V 0x0142
Address (0X) Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00003 2 Read
00004 3 Read
00005 4 Read
00006 5 Read
00007 6 Read
00008 7 Read
00017 0
DO Value
R/W
00018 1 R/W
00019 2 R/W
00020 3 R/W
00021 4 R/W
00022 5R/W
00023 6 R/W
00033 0
Counter Start (1) / Stop (0)
R/W
00034 1 R/W
00035 2 R/W
00036 3 R/W
00037 4 R/W
00038 5 R/W
00039 6 R/W
00040 7 R/W
00041 0
Clear Counter (1)
Write
00042 1 Write
00043 2 Write
00044 3 Write
00045 4 Write
00046 5 Write
00047 6 Write
00048 7 Write
