Advantech ADAM-6256 User Manual

ADAM-6200 User Manual 160
B.1.3 Analog Input Range code
Example The command asks the specific module at address 01h to send ana-
log input range code value from analog input channel 3.
ASCII Command: #01B03(cr)
Response: >010182(cr)
B.1.4 Analog Input Alarm Command Set
Range Code HEX
+/- 10V 0x0143
+/- 5 V 0x0142
+/- 1 V 0x0140
+/- 500 mV 0x0104
+/- 150 mV 0x0103
+/- 20 mA 0x0181
0 ~ 20 mA 0x0182
4 ~ 20 mA 0x0180
Command Syntax Command Name Description
$aaCjAhs Set Alarm Mode
Set the High/Low alarm in either Momentary or
Latch-ing mode
$aaCjAh Read Alarm Mode
Returns the alarm mode for the specified chan-
nels
$aaCjAhEs Enable/Dis-able Alarm
Enables/Disables the high/low alarm of the
specified channels
$aaCjCh Clear Latch Alarm Resets a latched alarm
$aaCjAhCCn Set Alarm Connection
Connects the High/Low alarm of a specified
input channel to interlock with a specified out-
put channel
$aaCjRhC Read Alarm Connection
Returns the alarm configuration of a specified
input channel
$aaCjAhU Set Alarm Limit
Sets the High/Low alarm limit value to a speci-
fied channel
$aaCjRhU Read Alarm Limit
Returns the High/Low alarm limit value of the
speci-fied channel
$aaCjS Read Alarm Status
Reads whether an alarm occurred in the speci-
fied channel
