Advantech ADAM-6256 User Manual

ADAM-6200 User Manual 180
C.1 Introduction
REpresentational State Transfer (REST) is a design style of software architecture for
Web application behaves and services including image indication, resource request
and response and message delivery. It can be developed compatible with popular
protocols or standards like HTTP, URI, XML, HTML. With the advantage of scalability,
simplicity and performance, it's already adopted in Web service by Amazon, Yahoo.
The Web service of ADAM-6200 is developed based on HTML5 language, if user
need to integrate this into other Web services, the following information/command list
should be referred for implementation.
C.2 REST Resources for ADAM
C.2.1 Analog Input
C.2.1.1 GET /analoginput/(all|{id})/value
Request
Thecontent‐typewillbe‘application/x‐www‐form‐urlencoded’.
{id}:istheAIchannelIDstartingfrom0
Examples:
UsethefollowingURItogettheAI‐0value.
http://10.0.0.1/analoginput/0/value
UsethefollowingURItogettheallAIvalues.
http://10.0.0.1/analoginput/all/value
Response
The content-type will be ‘text/xml’
IfresultisOK,thecontentwilllooklikebelow
<?xml version="1.0" ?>
<ADAM-6217 status=”OK”>
<AI>
<ID>0</ID>
<
VALUE>FFFF</VALUE>
</AI>
</ADAM-6217>
Ifresultisfailed,thecontentwilllooklikebelow
<?xml version="1.0" ?>
<ADAM‐6217status=”{error}”>
</ADAM-6217>
{error}:Theerrormessage.
Remarks
Ifthe{id}isoutofrange,theresponsewillreturnHTTPstatuscode501
(Notimplemented)

Advantech ADAM-6256 Specifications

General

Digital Input Channels	16
Digital Output Channels	16
Communication Interface	Ethernet
Input Voltage	10 to 30 VDC
Protocols	Modbus RTU
Storage Temperature	-20°C to +70°C
Humidity	10 to 95% RH

Summary

Chapter 1 Product Overview

1.2 Feature Highlights

Key features of the ADAM-6200 series, including installation, IT integration, and management.

Chapter 2 Product Specifications

2.1 General Specification

2.2 Analog Input Module (ADAM-6217)

Details the specifications for the ADAM-6217 analog input module.

2.3 Analog Output Module (ADAM-6224)

Details the specifications for the ADAM-6224 analog output module.

2.4 Digital Input/Output Modules (ADAM-6250/6251/6256)

Details specifications for ADAM-6250, 6251, and 6256 digital I/O modules.

2.5 Relay Output Modules (ADAM-6260/6266)

Chapter 4 System Configuration

4.1 ADAM.NET Utility (software)

4.3 Configure ADAM-6200 with ADAM.NET Utility

Guides users on configuring the ADAM-6200 module using the ADAM.NET Utility.

4.3.2 General Configuration

4.3.3 I/O Configuration

Details how to configure individual I/O channels for specific modules.

4.3.4 Peer to Peer

4.3.5 GCL

Introduces the Graphic Logic Condition (GCL) feature for standalone control.

4.3.6 Remotely Monitoring and Control via Web Server

Appendix A I/O Modbus Mapping Table

A.1 I/O Modbus Mapping Table

Appendix B ADAM-6200 ASCII Commands

B.1 ASCII Commands for ADAM-6200 modules

Appendix C REST for ADAM-6200

C.2 REST Resources for ADAM
