ADAM-6200 User Manual 24
2.5 Relay Output Modules (ADAM-6260/6266)
Relay Output Description
Channel
ADAM-6260: 5 Form C and 1 Form A
ADAM-6266: 4 Form C
Contact Rating
250 V
AC
@ 5A
30 V
DC
@ 5 A
Max. Switching Voltage
400 V
AC
300 V
DC
Max. Breaking Capacity 1250 VA
Frequency of Operation
360 operations/hour with load
72,000 operations/hour without load
Set/Reset Time 8 ms/8 ms
Mechanical Endurance
> 15 x 10
6
operations
Isolation between Contact:
1000 V
rms
Contact Resistance < 30 m
Insulation Resistance
> 10 G @ 500 V
DC
Digital Input Description
Channel ADAM-6266: 4
Dry Contact
Logic 0: Open
Logic 1: Closed to DI COM
Wet Contact
Logic 0: 0 ~ 3 V
DC
or 0 ~ -3 V
DC
Logic 1: 10 ~ 30 V
DC
or -10 ~ -30 V
DC
Input Impedance 5.2 k (wet contact)
Transition Time 0.2 ms
Frequency Input Range 0.1 ~ 3kHz
Counter Input 3kHz (32-bit+1-bit overflow)
Other Functions
Keep/Discard Counter Value when power off
Support Inverted DI Status
