ADAM-6200 User Manual 140
A.1.7 ADAM-6260 6-ch Relay Output Module
Address (0X):
Address (4X):
Address (0X) Channel Description Attribute
00017 0
DO Value
R/W
00018 1 R/W
00019 2 R/W
00020 3 R/W
00021 4 R/W
00022 5 R/W
00301 0
Clear GCL Counter
Write
00302 1 Write
00303 2 Write
00304 3 Write
00305 4 Write
00306 5 Write
00307 6 Write
00308 7 Write
Address (4X) Channel Description Attribute
40001 – 40002 0
Pulse Output Low Level Width
R/W
40003 – 40004 1 R/W
40005 – 40006 2 R/W
40007 – 40008 3 R/W
40009 – 40010 4 R/W
40011 – 40012 5 R/W
40013 – 40014 0
Pulse Output High Level Width
R/W
40015 – 40016 1 R/W
40017 – 40018 2 R/W
40019 – 40020 3 R/W
40021 – 40022 4 R/W
40023 – 40024 5 R/W
40025 – 40026 0
Set Absolute Pulse
R/W
40027 – 40028 1 R/W
40029 – 40030 2 R/W
40031 – 40032 3 R/W
40033 – 40034 4 R/W
40035 – 40036 5 R/W
