Advantech ADAM-6256 User Manual

137 ADAM-6200 User Manual
Appendix A I/O Modbus Mapping Table
A.1.6 ADAM-6256 16-ch Digital Output Module
Address (0X):
Address (4X):
Address (0X) Channel Description Attribute
00017 0
DO Value
R/W
00018 1 R/W
00019 2 R/W
00020 3 R/W
00021 4 R/W
00022 5 R/W
00023 6 R/W
00024 7 R/W
00025 8 R/W
00026 9 R/W
00027 10 R/W
00028 11 R/W
00029 12 R/W
00030 13 R/W
00031 14 R/W
00032 15 R/W
00301 0
Clear GCL Counter
Write
00302 1 Write
00303 2 Write
00304 3 Write
00305 4 Write
00306 5 Write
00307 6 Write
00308 7 Write
Address (4X) Channel Description Attribute
40001 – 40002 0
Pulse Output Low Level Width
R/W
40003 – 40004 1 R/W
40005 – 40006 2 R/W
40007 – 40008 3 R/W
40009 – 40010 4 R/W
40011 – 40012 5 R/W
40013 – 40014 6 R/W
40015 – 40016 7 R/W
40017 – 40018 8 R/W
40019 – 40020 9 R/W
40021 – 40022 10 R/W
40023 – 40024 11 R/W
40025 – 40026 12 R/W
40027 – 40028 13 R/W
40029 – 40030 14 R/W
40031 – 40032 15 R/W
