Advantech ADAM-6256 - 2.1 General Specification

ADAM-6200 User Manual 14
2.1 General Specification
Item Description
Ethernet 2-port 10/100 Base-TX (for Daisy chain)
Protocol Modbus TCP, TCP/IP, UDP, HTTP, DHCP
LED Indication
ADAM-6217: Status/Com, Link/Speed
ADAM-6224: Status/Com, Link/Speed
ADAM-6250: Status/Com, Link/Speed, 8x DI, 7x DO
ADAM-6251: Status/Com, Link/Speed, 16x DI
ADAM-6256: Status/Com, Link/Speed, 16x DO
ADAM-6260: Status/Com, Link/Speed, 6x RL
ADAM-6266: Status/Com, Link/Speed, 4x RL, 4x DI
Connector
Plug-in 5P/15P screw terminal blocks. Accepts wire size #14~22
AWG ,stripped length: 5 mm
Power Input
10 - 30 V
DC
(24 V
DC
standard)
Watchdog Timer System (1.6 second) and Communication (Programmable)
Dimension 110 x 60 x 27 mm
Protection
Built-in TVS/ESD protection
Power Reversal protection
Over Voltage protection: +/- 35 V
DC
Isolation protection: 2500 V
DC
Power consumption
ADAM-6217: 3.5W @24 V
DC
ADAM-6224: 6.0W @24 V
DC
ADAM-6250: 3.0W @24 V
DC
ADAM-6251: 2.7W @24 V
DC
ADAM-6256: 3.2W @24 V
DC
ADAM-6260: 4.5W @24 V
DC
ADAM-6266: 4.2W @24 V
DC
Operating temperature -10 ~ 70°C (14 ~ 158°F)
Storage temperature -20 ~ 80°C (-4 ~ 176°F)
Operating Humidity 20 ~ 95% RH (Non-condensing)
Storage Humidity 0 ~ 95% RH (Non-condensing)
Feature Highlights
Daisy chain connection with auto-bypass protection.
Remote monitoring and control with smart phone/pad.
Group configuration capability for multiple module setup.
Flexible user-defined Modbus address.
Intelligent control ability by Peer-to-peer and GCL function
Multiple protocol support: Modbus TCP, TCP/IP, UDP, HTTP,
DHCP
Web language support: XML, HTML 5, Java Script
System configuration backup
User Access Control
