51 ADAM-6200 User Manual
Chapter 4 System Configuration
4.3.2.2 Network
You can set up required network connection on this page.
Network Setting
You can select the Connection mode as DHCP or Static IP and configure the MAC
address, IP address, Subnet address, Default gateway and Host Idle (timeout).
Port Setting
You can set up the network port for DataStream and P2P/GCL function.
Note! 1. Static IP mode is set 10.0.0.1 as default.
2. Network Diagnostic (Default: ON) - ADAM module will actively
monitor and diagnose the Ethernet switch periodically when it's
enabled. However, if you have no need to use Ethernet ports for
communication, please notice to disable this function.
Module Ethernet Protocol and Port
TCP Modbus TCP 502
Download TCP 5450
Config. Upload TCP 5452
Web Server TCP 80
Search Engine UDP 5048
ASCII CMD UDP 1025
P2P/GCL UDP 1025 Configurable
Data Stream UDP 5168
GCL remote Message UDP 5168
