ADAM-6200 User Manual 132
Address (4X):
00049 0
Clear Overflow
R/W
00050 1 R/W
00051 2 R/W
00052 3 R/W
00053 4 R/W
00054 5 R/W
00055 6 R/W
00056 7 R/W
00057 0
DI Latch Status (1)
R/W
00058 1 R/W
00059 2 R/W
00060 3 R/W
00061 4 R/W
00062 5 R/W
00063 6 R/W
00064 7 R/W
00301 0
Clear GCL Counter
Write
00302 1 Write
00303 2 Write
00304 3 Write
00305 4 Write
00306 5 Write
00307 6 Write
00308 7 Write
Address (4X) Channel Description Attribute
40001 – 40002 0
Counter/Frequency Value
Read
40003 – 40004 1 Read
40005 – 40006 2 Read
40007 – 40008 3 Read
40009 – 40010 4 Read
40011 – 40012 5 Read
40013 – 40014 6 Read
40015 – 40016 7 Read
40017 – 40018 0
Pulse Output Low Level Width
R/W
40019 – 40020 1 R/W
40021 – 40022 2 R/W
40023 – 40024 3 R/W
40025 – 40026 4 R/W
40027 – 40028 5 R/W
40029 – 40030 6 R/W
