8.2 Diagnostic Trouble Codes
104
Operator’s Manual | SM100 | 5100064108 | 08/2022 | [en-US]
DTC (J1939 Format) Description J1939 Lamp Status
Remark
SPN
(Hex)
SPN
(DEC) FMI MIL RSL AWL PL
1D 29 4 Accelerator Pedal Position Sensor "B" :
Shorted to low source
X
3 Accelerator Pedal Position Sensor "B" :
Shorted to high source
X
2 Accelerator Pedal Position Sensor "B" : Inter-
mittent fault
1 Accelerator Pedal Position Sensor "B" : Be-
low normal operational range (SAE J1843)
X
0 Accelerator Pedal Position Sensor "B" :
Above normal operational range (SAE J1843)
X
8 Accelerator Pedal Position Sensor "B" : Com-
munication fault
X
15 Accelerator Pedal Position Sensor "B" : Not
available (SAE J1843)
X
6C 108 4 Barometric Pressure Sensor : Shorted to low
source
X
3 Barometric Pressure Sensor : Shorted to high
source
X
2 Barometric Pressure Sensor : Intermittent
fault
470 1136 4 E-ECU Internal Temperature Sensor: Shorted
to low source
X
3 E-ECU Internal Temperature Sensor :
Shorted to high source
X
2 E-ECU Internal Temperature Sensor : Inter-
mittent fault
0 E-ECU Internal Temperature : Too High X
6E 110 4 Engine Coolant Temperature Sensor: Shorted
to low source
X
3 Engine Coolant Temperature Sensor: Shorted
to high source
X
2 Engine Coolant Temperature Sensor : Inter-
mittent fault
0 Engine Coolant Temperature : Too High X
437 1079 4 Sensor 5V : Shorted to low source X
3 Sensor 5V : Shorted to high source X
2 Sensor 5V : Intermittent fault
9E 158 1 System Voltage : Too Low X
0 System Voltage : Too High X
436 1078 4 Engine Fuel Injection Pump Speed Sensor :
Shorted to low source
X
(Both)
X
(Either)
