AEM SM100 - Electrical System; Hydraulic System; Drive System; Controls

Technical Data
Electrical System 10.4
111
[en-US] | 08/2022 | 5100064108 | SM100 | Operator’s Manual
10.4 Electrical System
Item Units SM100
Alternator A 55A
Starter kW 1.1 kW
Battery CCA 12V 650 CCA
10.5 Hydraulic System
Item Units SM100
Pump type — Gear
Auxiliary flow rate l/min (gpm) 49.3 (13.0)
Auxiliary relief pressure bar (psi) 210 (3,045)
Lift and tilt port relief pressure bar (psi) 230 (3,356)
Charge/pilot pump flow rate l/min (gpm) 14.5 (3.83)
Charge/pilot pressure bar (psi) 20 (290)
Hydraulic function time:
Raise lift arms
Lower lift arms
Bucket dump
Bucket rollback
seconds
3.08
2.03
1.59
1.31
10.6 Drive System
Item Units SM100
Drive type — Hydrostatic
Relief pressure bar (psi) 300 (4,351)
10.7 Controls
Item SM100
Type Hydraulic pilot
Pattern ISO
Workgroup type ISO manual lever
Engine speed Electronic dial
Service brake Hydrostatic trans
Parking brake Spring applied pressure release (SAPR)
Parking brake control Automatic/switchable
