Operation
6.19 Operating on Slopes
56
Operator’s Manual | SM100 | 5100064108 | 08/2022 | [en-US]
6.19 Operating on Slopes
WARNING
Crushing hazard
Do not operate the machine sideways on slopes. The machine can tip or roll
over, even on stable ground.
► Operate the machine straight up and down slopes with the heavy end of
the machine uphill.
► Do not turn with the machine on a slope.
► Keep the lift arm low to the ground.
► Maintain control of the machine by adjusting the travel and movements
speeds for the operating conditions.
Overview
When operating on slopes or hills, special care must be taken to reduce the
risk of personal injury or damage to the machine. The maximum operating
angle rating is 17.5°.
The risk zone on a slope is different from the one on a level surface. Stop
machine operation immediately as soon as someone enters the risk zone.
For further information, see Safety Guidelines for Operating the Machine on
page 14.
Fig.32: Traveling with a load
Traveling with a load
• When loaded, point the load uphill on slopes.
• To avoid tipping, carry loads close to the ground, yet high enough to
clear obstacles.
• Drive up and down slopes slowly.
• Do not drive diagonally across slopes.
• Do not make sharp turns on slopes, or the machine may roll over.
Fig.33: Traveling without a load
Traveling without a load
• When unloaded, point the back of the machine uphill on slopes.
• Keep the lift arm low to the ground, yet high enough to clear obstacles.
• Drive up and down slopes slowly.
• Do not drive diagonally across slopes.
• Do not make sharp turns on slopes, or the machine may roll over.
Surface conditions
• Pay attention to changing surface conditions while operating the ma-
chine. Adjust speed and travel direction as necessary to maintain safe
operation.
• Machine stability and traction can be severely reduced when operating
on uneven or rough terrain, rocky soils, or wet or loosely packed surface
materials.
