4.2 Machine Overview
4
5
6
7
10
9
12
11
13
8
1
3
2
10
14
14
7
14
14
Fig.3: Machine components
Ref. Component Ref. Component
1 Handrails 2 Controls
3 Display 4 Diesel fuel fill
5 Attachment (options available) 6 Auxiliary hydraulic couplers
7 Tracks 8 Hydraulic oil fill
9 Lift arm 10 Lift arm support device
11 Hood 12 Operator platform
13 Operator presence pedal 14 Tie-down points
