3.
Install the hub in its place towards the
crankshaft gear.
NOTE: The conical sleeve must not be
installed at this stage!
4.
Press the hub firmly against the gear and
push cleaned and dry conical sleeve onto the
crankshaft.
5.
Lubricate the hub nut thread, rear surface
and outer surface (the surfaces affecting nut
friction) with vaseline.
NOTE: Do not use oil, it may run into the
conical surfaces.
Fig. 69
6.
Install the hub nut onto the crankshaft thread
and tighten it to the correct torque value.
Fig. 70
3. Maintenance
4th Generation Engines 3-43
