2.
Check the condition of the rubber element.
3.
Change the damper, if
• the rubber pieces have been loosened
from the element
• the rubber has been pressed to a depth of
more than 3.5 mm
• the outer circumference is slack
• the outer circumference moves in the
direction of the shaft.
Fig. 46
3.5.7 Viscose type vibration damper
(1) Housing
(2) Damper mass
(3) Liquid cavity
(4) Bushing
Engine has a vibration damper of "viscose type".
Inside the damper there is a housing filled with
stiff silicone oil, in which the damping substance
has very small tolerances.
NOTE: Even a small dent makes the vibration
damper inoperative. Do not remove it by turning
forcibly and be careful not to damage it when it is
loose. If you detect a dent on the outer surface, do
not re-install the damper in the engine.
NOTE: If you are making the installation mark on
the vibration damper, use an electric pen, do not
tap it.
Fig. 47
3. Maintenance
3-30 4th Generation Engines
8370 79492
