2.1.16 Turbocharger
S100 S200 S300 S400
Axial clearance maximum 0.10 mm 0.10 mm 0.12 mm 0.11 mm
Radial clearance (compressor end) maximum 0.82 mm 0.88 mm 0.88 mm 1.00 mm
Compressor wheel lock nut torque 6.8 Nm 13.6 Nm 20.3 Nm 41.8 Nm
Compressor housing screws torque 13.6 Nm 13.6 Nm 13.6 Nm 10.2
Nm
[1]
Turbine housing screws torque 21.0 Nm 21.0 Nm 21.0 Nm 10.2
Nm
[1]
[1]
V-band torque
