AGCO Power 49 - Power Take-Off; Fan Drive Device

3.9.4 Power take-off
The engines use a transmission that can be
equipped with a PTO run from the camshaft gear.
The PTO can run e.g. a hydraulic pump.
NOTE: Use molybdenite-sulphide (MoS2) ball
bearing grease (NLGI 2) for the grooves of the
hydraulic pump shaft and the coupling sleeve.
Fig. 71
3.9.5 Fan drive device
Procedure
1.
Assemble the drive device.
a) Fit the shaft, inner bearing and the lock
ring.
Press the shaft into position so that the
ball bearings do not transmit the
pressure.
b) Fill the bearing housing partially with heat-
resistant ball bearing grease (NLGI 2).
c) Fit the spacer sleeve, the outer bearing
and the lock ring.
d) Note the position of the outer bearing
during assembly.
2.
Tap the blocking plug (if removed) into
position with fitting drift 9025 87400.
3.
Fit the belt pulley, washer and nut.
4.
Tighten the nut to 350 Nm.
Fig. 72
