2.3 Special tools
2.3.1 Cylinder block tools
Fig. 1
Ref. Description Order
number
33 44 49 66 74 84 98
1 Puller for cylinder liner 9051 73100 xxxxx
1 Puller for cylinder liner 9104 51500 x x
2 Milling cutter for cylinder
liner seat
9101 65600 xxxxx
2 Milling cutter for cylinder
liner seat
9104 52000 x x
Spare cutting blade for
milling cutter
9045 87600 xxxxxxx
3 Drift for 40 mm cup plug 9052 46620 xxxxxxx
4 Drift for 16 mm cup plug 9052 46650 xxxxxxx
5 Drift for fitting camshaft cup
plug
9025 87400 xxxxxxx
6 Press tool for cylinder liner 9101 66300 xxxxxxx
7 Holder for dial gauge 9025 79200 xxxxxxx
