Object Nm
Injector (CRI2_16) retaining screw 28
Injector wire nuts (M4) 1,5
High pressure pump gear nut 80
Fuel filter elements 40
Pre-filter water detector 6
Compressor gear nut (1 and 2 cylinder) 160 (LH thread)
Self carrying oil sump screws and engine bracket screws
Thread Nm
M8 35
M10 80
M12 140
M14 200
M16 300
M20 700
M22 700
General torque values
Always use the torque values listed in the
following table when specific torque values are not
available.
Use a washer with the aluminium parts.
Thread Strength class
8.8 10.9
M8 25 Nm 35 Nm
M10 50 Nm 75 Nm
2. Specifications
4th Generation Engines 2-21
