Procedure
1.
Replace the mounting bracket O-ring and
shaped gasket, if the CCV filter has been
removed
2.
Fit the CCV system hoses.
Make sure that there are no unnecessary
bends or creases on the CCV system hoses.
The hose line must be straightforwardly
ascending as shown in the figure.
3.
Make sure that the monitoring hole for
ambient pressure is not blocked.
Fig. 84
3. Maintenance
4th Generation Engines 3-51
8370 79492
