Figure A.7 Aligning the Pin Protection Block on the Dry Station (Note: Your pin
protection block may look different than the one in the photo.)
Alignment pins
Alignment pins on the
bottom of the pin
protection block must fit
into the front-left and
back-right station wells
(circled in yellow below).
L-shaped channel
The alignment bar
must go into the
L-shaped channel.
Alignment bar
