Chapter 3 Methods and Mappings62
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
96 MTP to 96
SpectroCHIP Array
mapping file
Use this mapping file to dispense from 96-well plates to 96 SpectroCHIP Arrays. This
mapping file requires the 6-pin format. A maximum of two plates and two SpectroCHIP
Arrays can be run using this mapping file. Each plate is dispensed to one of the
SpectroCHIP Arrays.
NOTE
This is the only predefined mapping file available on a 6-pin instrument. This is different from a 24-
pin instrument adapted to 6-pin format, which has additional predefined mapping file available.
Figure 3.4 96 MTP to 96 SpectroCHIP Array
MTP 1 MTP 2
SCOUT plate with 96 SpectroCHIP Arrays
96-well
microtiter plates
