Chapter 1 Introduction6
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
Figure 1.2 Instrument Front
Stop Button
Immediately stops
motion
Touchscreen
Controls the
instrument
Figure 1.3 Instrument Back: Power Switch and Ports
For more information about these ports, see External ports, page 12.
Power Switch
I/O Port: Future expansion
USB 2.0 Ports (2): Data transfer,
keyboard, or mouse
VGA Port: External display
Ethernet Port: Sample tracking, data
transfer
